chuyên nghiệp làm cho chất lượng tốt, cung cấp sản phẩm hoàn hảo và dịch vụ cho mỗi khách hàng.
 |
| Place of Origin: | China(Mainland) |
| Hàng hiệu: | SCX |
| Chứng nhận: | CE,ISO,FCC,UL |
| Model Number: | SCX-P1.667 |
| Minimum Order Quantity: | 5sqm |
|---|---|
| Giá bán: | 2800-3000USD/sqm |
| chi tiết đóng gói: | Thùng carton, gỗ và bay. |
| Delivery Time: | 12-15 working days. |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 5000sqm/month |
| Tube chip color: | Full Color | Pixels: | 1.667mm |
|---|---|---|---|
| Screen dimension: | Customized | Usage: | Indoor |
| Display function: | Video | Warranty: | 2 Years |
| Brightness: | 1200cd/sqm | Module size: | 200*150mm |
| Led chip: | Epistar | Life span: | 100000hours |
1) Guidance service: If customers have any installation or use problems, our company can provide online guidance.
For large projects, our company can provide one week of training for your company's engineers free of charge. If the customer can afford the relevant expenses,
Our engineers can go to the customer's country/region for on-site guidance.
2) Warranty period: two years after delivery.
3) Maintenance principle: timely response, solve problems as soon as possible, and ensure use.
4) Maintenance terms: During the maintenance period, all maintenance costs are waived.
Under normal use and storage conditions, the equipment is the responsibility of our company.
If the product has quality problems, our company will repair and replace parts free of charge.
After the maintenance period, only material costs are charged, and no labor costs are charged.
Specifications:
| SMD P1.667 | |||||
| Resolution/mm | 1.667 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 360000/square meter | ||||
| Module resolution | 120x90mm | ||||
| Module size/mm | 200x150mm | ||||
| View distance | 14-300m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >7500cd/square meter | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/30 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
